62.5 KVA Ricardo Diesel Generator We have been directly importing Passenger lifts, Generators, and all kinds of pumps & motors for ten years now. Especially, diesel generators from 5 kw to 500 kVA with different diesel engines and generators (brands: Ricardo, Lambert, Cummins, Perkins, Deutz, etc.). Matched with Stamford & Copy Stamford, Marathon, and another reliable alternator brand. Open Type, silent low noise soundproof type, more types for optional.

Engine Details: 50 kilowatt generator.

• Engine Name: Ricardo
• Engine Power Capacity Prime Load: 62.5 kVA / 50 kW
• Rated Standby: 69 kVA / 55 kW
• Assemble Brand Available: Kofo, Power AC, LW, FMW
• Model of Generator Engine: 4105ZD Ricardo Series
• Number of Cylinders: Four Cylinders
• Cooling System: Water Cooled
• Generator Imported & Origin: China

Technical Features: 50 kw diesel generator price.


• Alternator Name: Stamford
• Alternator wire use: Full Copper Build
• Type of this generator Alternator: Brushless and STC Both Available
• Panel of Generator: Full Digital
• Charging: By Dynamo Charging
• Factor: 0.8
• Alternator Speed (RPM): 1500 RPM
• Rated Voltage: 220–380 Volt.
• No. of Phase System: Three Phase
• No. of Wire System: Four Wire System
• Noise Level System: 69 dBA
• Capacity of Fuel Tank: 105 Litres

Fuel Usage:

• Fuel Consumption per hr/ltr: 6.5 ltr/hr
• Fuel consumption at Different Loads:
  • 25%: 3.5 L/hr
  • 50%: 4.5 L/hr
  • 75%: 5.5 L/hr
  • 100%: 6.5 L/hr

Additional Information:

• Available: Foreign Canopy, Open, Local Canopy
• Weight: 1500 kg
• Generator Dimension Meter: 2.0m X 0.82m X 1.30m
• Mount: 01 Set (04 Piece)
• Battery: 01 Set Battery (Capacity: 12 Volt.)
• Charging System: (01) Set Charger
• Warranty Days: 365 Days
• Payment System: 100% payment before delivery.

Additional information
Weight    1030 kg
Dimensions    2250 × 930 × 1200 cm
Name    62.5 kva generator, 62 kva generator price, 62.5 kva generator price, 63 kva generator price, 50 kw 3-phase generator.
Engine, Model    Ricardo, R4105ZD.
Rating in prime    62.5 kva, 50 kw.
Rating in standby    69 kVA, 55 kW.
Origin / Place    China.
Fuel consumption at 100% load    205g/kW.h
Available genset    Canopy / Soundproof / Open/
Alternator make    Stamford Copy
Phase and wire    3 phase, 4 wires.
Excite type    Single Bearing, Close Coupled. Brushless, self-exciting, AVR.
Protection class    IP23.
Canopy Size (L*W*D)CM    188*72*120.
Volt    440v-230v. 50 hz.
Bore x Stroke    102mm*120mm.
Cylinders    Four Cylinders.
Warranty deadline    12 months, 1000 hours.
